Description
SecoLok Panel Mount Ball Valve
Specification
- Valve Type: Ball Valve
- Valve Size: 1/8″ to 2″ / 6 mm to 50 mm
- Connection Type: NPT, BSP, Twin/Single Ferrule
- Function: 2 Way, 3 Way, 4 Way, 5 Way
- Pressure Rating: 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI
- Handle Type: Fenolic handle, lever handle, and more (on request)
- Seal Ring Material: PTFE, PVDF, Delrin, PEEK, Graphite
For high-pressure diversion, a 10,000 PSI (700 Bar) ball valve with polyamide or KEF-F seats is available.
- Body Material: Brass, Stainless Steel, Steel, Hastelloy, Super Duplex (and more on request)
- Temperature Range: -5°C to 250°C
Applications
SecoLok panel mount ball valves are used in a wide range of applications, including:
- Pneumatic and hydraulic systems
- Oil and gas manifold skids
- Gas panels
- Chemical processing
- Food and beverage processing
- Pharmaceutical manufacturing
- Water and wastewater treatment
- HVAC systems
- CNG booster systems
Construction Standards
SecoLok panel mount ball valves are manufactured to meet a variety of construction standards, including:
- ANSI/ASME B16.34
- MSS SP-110
- API 6D
- NACE MR0175
Why Choose SecoLok Panel Mount Ball Valves?
SecoLok panel mount ball valves are known for their quality, reliability, and durability. They are also easy to install and maintain. SecoLok offers a wide range of panel mount ball valves to choose from, so you can find the perfect valve for your specific application.
Contact SecoLok today to learn more about our panel mount ball valves and other precision engineering products.
