Description
Product Overview: The SecoLok AS SL1 is a premium high-pressure inlet filter designed for demanding industrial applications where reliable filtration and safety are paramount. Engineered for use with compressed air, technical gases, liquids, and oils, this robust filter ensures optimal performance even under extreme conditions.
Key Features:
- Pressure Handling: Standard maximum inlet pressure up to 220 bar (3190 psi). Enhanced version available for pressures up to 350 bar upon request.
- Connection Options: Female threaded connections available in G 1/4, G 3/8, G 1/2, G 1, and G 3/4. Other connection types can be provided on request.
- Filtration Efficiency: Replaceable filter elements with options:
- 5 μm (sintered stainless steel)
- 50 μm (sintered stainless steel)
- Coalescing 0.01 μm (borosilicate fiber with 99.99% efficiency)
- Material Composition: Built with corrosion-resistant stainless steel AISI 316L.
- Seal Material: Available seal options include NBR, EPDM, FPM, FVMQ, and FFKM for enhanced compatibility with various media.
Technical Specifications:
- Operating Temperature: Standard range from -4°F to +140°F. Extended range available from -76°F to +608°F upon request.
- Weight: Approximately 5.5 lbs.
Accessories and Spare Parts:
- Accessories: Wall mounting bracket for secure installation.
- Spare Parts: O-ring set and filter cartridge replacements available for easy maintenance.
The SecoLok AS SL1 is the ideal solution for high-pressure filtration needs, ensuring safety, efficiency, and longevity in critical industrial environments.
